A nerve conduction study and needle EMG answer a physiological question: is the nerve working, and if not, where and how badly. That is a different question from the one imaging answers, which is why a normal MRI and an abnormal nerve study frequently sit in the same file.
This guide covers what the test identifies, what it rules out, and the conditions it is poor at detecting.
The four questions the test is built to answer
Jim Lewis R. NCS.T, CNCT frames the whole examination as a sequence of localising questions: is there a root lesion — a pinched nerve in the neck or the back; is the problem at the neuromuscular junction, and is it presynaptic or postsynaptic; is there a myopathy; is there an upper motor neuron lesion.
Everything the study does serves that sequence. Stimulating at more than one point along a nerve, comparing one side against the other, and sampling muscles that share a nerve root but differ in their route are all ways of narrowing down where.
Focal compression neuropathies
This is the test's strongest application, because compression produces a change at a known location that the study can pin down precisely.
- Carpal tunnel syndrome — median nerve at the wrist, the most common referral by a wide margin
- Ulnar neuropathy at the elbow — the second most common, and one where localisation genuinely changes management
- Peroneal neuropathy at the fibular head — a frequent cause of foot drop
- Radial neuropathy, including compression in the spiral groove
Distribution is what separates these from their mimics, and the detail is unforgiving. Lewis uses the classic teaching example: in ulnar lesions at the elbow, numbness may extend to the back of the hand, whereas in compression at Guyon's canal at the wrist “the dorsum of the hand is preserved” because that sensory branch leaves the nerve higher up. As he puts it, the work is “putting pieces of a puzzle together — do they make sense? Do they fit?”
Generalised peripheral neuropathy
Where compression is focal, neuropathy is diffuse, length-dependent and usually symmetrical — longest nerves affected first, which is why symptoms start in the feet.
Certain nerves are chosen specifically for this. Lewis singles out the sural sensory and superficial peroneal studies, describing the sural as “a really, really great nerve because it's a very long, purely sensory nerve” — qualities that make it sensitive to diabetic and alcohol-related neuropathies.
The study can also distinguish a predominantly demyelinating neuropathy from a predominantly axonal one, which narrows the causes worth investigating.
Radiculopathy
A pinched nerve root in the neck or lower back is where electrodiagnostic testing adds something imaging cannot.
An MRI shows anatomy. Disc bulges are extremely common in people with no symptoms at all, so imaging routinely finds a plausible structural culprit that may be innocent. The needle study shows whether a root is actually failing to supply its muscles.
Localisation comes from muscle selection, and Lewis's worked example makes the logic clear: “if we stick the needle in the deltoid muscle, we're looking at the axillary nerve, and we're looking at C5. Well, then if I move down to the biceps, I'm also looking at the C5 nerve root, but it's a different place through the brachial plexus.” A finding in both suggests the root; a finding in one suggests something further along.
One limitation matters clinically: the needle findings take weeks to appear after a root is injured. Tested too early, the study can be normal in a patient with a genuine radiculopathy.
Brachial and lumbosacral plexopathy
Plexus injuries are where the study is hardest and most valuable, because the anatomy is complex and the clinical picture rarely maps cleanly onto a single nerve or root.
Lewis notes that a good deal of the brachial plexus can be covered with sensory studies alone — less uncomfortable for the patient, and informative because those fibres lie distal to the dorsal root ganglion and so behave differently from root lesions. That distinction is diagnostic in itself: preserved sensory responses in a numb limb point toward a problem at the root rather than the plexus.
Side-to-side comparison is also at its most useful here, since plexopathy is typically one-sided.
Neuromuscular junction disorders and muscle disease
These require techniques beyond the standard study, and the classification Lewis teaches is worth knowing because it determines which technique is used.
Myasthenia gravis is postsynaptic. Botulism and Lambert-Eaton syndrome are presynaptic. Repetitive stimulation and, in selected cases, single-fibre EMG are the tools — the latter reserved for tertiary centres, because as Lewis notes it is “technically difficult”, takes 45 minutes to an hour on its own, and “requires a lot of patient cooperation.”
Myopathy shows a characteristic needle pattern: short-duration, low-amplitude motor units with a full interference pattern at low amplitude — the opposite of the reduced recruitment seen in nerve injury.
Motor neuron disease produces widespread denervation across muscles supplied by different nerves and roots, a pattern no single compression can explain.
What it cannot diagnose
Being clear about the limits prevents a normal result being misread as reassurance it cannot provide.
- Small-fibre neuropathy. The study assesses large myelinated fibres. Burning, tingling and temperature-related pain from small-fibre involvement can coexist with an entirely normal study.
- Pain from joints, tendons or muscle. Nothing in the study measures these.
- Central nervous system disease. Brain and spinal cord conditions are outside its scope, though upper motor neuron signs may be inferred indirectly.
- Structural anatomy. It cannot see a disc, a tumour or a cyst. It shows function, not form.
- Very recent injury. Needle changes take weeks to develop.
The finding has to fit the patient
The phrase Lewis returns to throughout the course is whether a result fits clinically. Electrodiagnostic findings are not self-interpreting; they are read against the history and the examination, and a finding that contradicts a clear clinical picture is a reason to interrogate the study.
The first things to check are technical. Limb temperature above all — cold nerves conduct slowly and mimic demyelination. Then the distances, then which muscles were sampled. As he puts it, it always comes back to how the pieces fit.
